So what have I got?

Machines

I have the following machines

Other hardware

  • 1 x Facit 4012 paper tape winding machine (got it 2017-07-14)
  • 1 x ND13-310 Facit 4070 paper tape punch (got it 2017-07-14). Lots of documentation in the facit directory on Bitsavers[1]
  • 1 x ND11-671 Digitronics 2540 paper tape reader (got it 2017-07-14). Operation and maintenance manual on Bitsavers[2].
  • 1 x Tandberg TDV5010 keyboard (got it 2019-04-09)
  • 1 x Tandberg TDV 1200 terminal (got it 2019-09-27). Not working - needs to be repaired.

Software

disks

2016-05-28: I got some removable disks (cartridge disks? disk packs?)

  • 1 x type CDC Model 9848-24
  • 1 x type Control Data Model 9848-24
  • 3 x type Control Data Model 848-24

Perhaps all are the same model?

floppies

5.25 inch

The 5.25 inch floppies I have.

2016-07-21: I visited Burbas in Sweden, and got all the 5.25 inch floppies with ND software he had. This includes three large binders (blue, ND logo) with the software from Bert Thomas' announcement on cc-talk back in 2008. An index sheet in one of the binder says that this software was running on system 3081.20557. Most of the software comes with documentation (PD, PI sheets) on paper. Numbers in parenthesis is where I have substituted the new numbering scheme from ND (add "2" to the front of any five-digit number).

  • (ND-210005U) ND-10005U Subsystem Package, 32 bits floating format. floppies: ND-10005U, 210628F01-XX-01D
  • ND-210079N NOTIS-WP for ND-100. floppies: 210079N07-XX-01D, 210079N07-XX-02D, 210079N07-EN-01D, 210079N07-EN-02D,
  • ND-210166F SIBAS II for ND-100. floppies: 210166F02-XX-01D, 210166F02-XX-02D,
  • ND-210185E ACCESS for ND-100. floppies: 210185E02-XX-01D, 210185E02-EN-01D,
  • ND-210193C NOTIS-RG for ND-100. floppy: 210193C02-EN-01D,
  • ND-210315F00 (10315F) Accounting system for SINTRAN III, 48 bits floating format). floppy: 210315F00-XX-01D,
  • ND-210337I Backup-System. Floppy: 210337I04-XX-01D,
  • ND-210373L X-Message. floppy: 210373L03-XX-01D,
  • ND-210375C Telefix for User Sites. Floppy: 210375C00-XX-01D,
  • ND-210400B Subsystem Package II. Floppy: 210400B00-XX-01D,
  • ND-210455G VTM terminal tables (Standard). Floppy: 210455G03-XX-01D,
  • ND-210507B Software Keys. Floppy: 210507B01-XX-01S (incorrectly named?). Also labeled "Legal numbers: 210185, 210729".
  • ND-210518C User-Environment. Floppies: 210518C02-XX-01D, 210518C02-XX-02D, 210518C02-EN-01D,
  • ND-210523F Test programs for ND-100/110. Floppy: 210523F01-XX-01D,
  • ND-210523G Test programs for ND-100/110/120. Floppies: 210523G02-XX-01D, 210523G02-XX-02D. Images: 210523G02-XX-01D.image.gz, 210523G02-XX-02D.image.gz or both in a zip file: 210523g02.zip
  • ND-210523H Test Programs for ND-100/110/120 (for internal use only). floppies: 210523H00-XX-01D, 210523H00-XX-02D,
  • ND-210534B JEC (Job Execution Control). Floppy: 210534B00-XX-01D,
  • ND-210628F SINTRAN III VSE/VSX Utility programs. Floppy: 210628F01-XX-01D,
  • (ND-210634A) ND-10634A Memory To floppy dump (MEMTOF-100). Floppy: no directory name
  • ND-210691C NOTIS-DS for ND-100. floppies: 210691C02-EN-01D, 210691C02-EN-02D, 210691C02-EN-03D,
  • ND-210721C BRF-Linker for ND-100.. floppy: 210721C00-XX-01D,
  • (ND-210724B) ND-10724B NOTIS-BG for ND-100. floppies: 10724B04-EN-01D, 10724B03-XX-02D, 10724B03-XX-03D,
  • (ND-210758B) ND-10758B NOTIS-BG for ND-100 (Business Graphics) 32 bits floating format. floppies: 10758B04-EN-01S, 10758B03-XX-02S, 10758B03-XX-02S,
  • ND-210729C UNIQUE-II SIBAS for ND-100. floppy: 210729C03-XX-01D,
  • ND-210729C UNIQUE-II SIBAS ND100. floppy: 210729C06-XX-01D,
  • ND-210913A SINTRAN III Monitor Call Package. floppy: 210913A00-XX-01D,
  • ND-211005C UNIQUE Text System. floppy: 211005C04-EN-01D,
  • 2 x ND-211024C SINTRAN III Configuration Program. Floppies: 211024C01-XX-01D,
  • ND-211056A SPRINT Spooling system. floppies: 211056A02-XX-01D, 211056A02-XX-02D, 211056A02-EN-01D,
  • ND-211065C (NOTIS-)RP for ND-100. floppy: 211065C02-EN-01D,
  • ND-211067A Mass storage Utilities. Floppy: 211067A02-XX-01D,
  • ND-211068A Operator Environment. floppies: 211068A00-XX-01D, 211068A00-XX-02D, 211068A00-EN-01D, 211068A00-EN-02D,
  • ND-211187A Disk Restore. floppies: 211187A00-XX-01D, 211187A00-XX-02D (not directory format), 211187A00-XX-03D (not directory format),
  • 2 x ND-220021K10 Patch-Sin-K-5400-VSX, Floppies: 220021K10-XX-01D,
  • 2 x ND-220046K03 SINTRAN III/VSX-500 (standard system D). Floppies: N-220046K03--01D, N-220046K03--02D,
  • a floppy labeled "MEDITEBS specials", "DIR: NAME: MEDITEBS", "User name: FLOPPY-USER", "8 maart 1990". Also listings of FORTRAN programs to work on SIBAS databases. Image: MEDITEBS.image.gz.

He also gave me a blue plastic floppy box (for 5.25 inch floppies), labeled "Inmac Plus 80", which contains three floppies that Jonny (of sintran.com) made for him:

  • SINTRAN III version M, 2008.10.20. Floppies: 250306M06-XX-01D, 250306M06-XX-02D, 250306M06-XX-03D

2013-10-27: a 5.25 inch floppy image (uncompressed, I simply used dd). Although it was labeled "URD" something on the (paper) label, it turns out it had something else on it. Looks like it has PERFORM, FILE-MAN and some U-E files on it. Unfortunately, I have not recorded from where I got this floppy.

  • S12 floppy (image). Contents:
tingo@kg-core1$ ndfs -tl s12_19851220.image
Directory name            : s12
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I       34 pages    270336 bytes 1985-12-20 07:50:45 (system)perform-g00:prog
  0   1: I        3 pages      2987 bytes 1985-12-20 07:50:49 (system)perform-lib-g00:mcro
  0   2: I        2 pages      1932 bytes 1985-12-20 07:50:50 (system)perf-500-lib-g00:mcro
  0   3: I       47 pages     95232 bytes 1986-11-11 09:43:23 (system)ue-ermsg-en-b02:old
  0   4: I       42 pages     84480 bytes 1985-12-20 07:54:57 (system)ue-ermsg-eng-a03:err
  0   5: I       25 pages     49664 bytes 1985-12-20 07:55:01 (system)ue-ermsg-nor-a00:err
  0   6: I       52 pages    106240 bytes 1985-12-20 07:55:05 (system)ue-ermsg-en-b03:err
  0   7: I       47 pages     96256 bytes 1985-12-20 07:55:10 (system)ue-ermsg-no-b02:err
  0   8: I       21 pages    137216 bytes 1985-12-20 07:53:38 (system)file-man-pri-b00:prog
  0   9: I      115 pages    251904 bytes 1985-12-20 07:54:29 (system)file-man-no-b00:prog
  0  10: I        1 page       1527 bytes 1985-12-20 07:54:42 (system)ue-load-no:mode
Directory size: 611 pages
Bit file size : 1 page

2013-02-11: I visited a kind man who gave a few 5.25 inch floppies with ND software on it, plus a sealed box of unused floppies (3M - DS, HD - 5.25 inch, box of 10). The ND floppies are

tingo@kg-t2$ ndfs -tl pc-link.image
Directory name            : nd-10561a
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I       11 pages     22528 bytes 1984-02-08 20:08:34 (floppy-user)pc-link:prog
  0   1: I       38 pages     76288 bytes 1984-02-08 20:09:31 (floppy-user)vtm-compound-a-c:prog
  0   2: I       44 pages     90112 bytes 1984-02-08 20:10:42 (floppy-user)vtm-compound-d-c:prog
  0   3: I        2 pages      1611 bytes 1984-02-08 20:12:20 (floppy-user)vtm-all-types:vtm
  0   4: I        1 page       1092 bytes 1984-02-08 20:13:14 (floppy-user)ddb079-a-a:vtm
Directory size: 611 pages
Bit file size : 1 page
  • 210455G02-XX-01D VTM Terminal tables (Standard) release date 870626 870618 (the floppy label is crossed out) (gzipped image). Contents:
tingo@kg-t2$ ndfs -tl ./test.image
Directory name            : 210455g02-xx-01d
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: C        3 pages       602 bytes 1987-04-09 09:56:43 (floppy-user)ddb002-7s-g02:vtm
  0   1: C        3 pages       632 bytes 1987-03-16 14:55:39 (floppy-user)ddb003-7s-g02:vtm
  0   2: I        1 page        602 bytes 1987-03-16 14:54:23 (floppy-user)ddb011-7s-g02:vtm
  0   3: I        1 page        887 bytes 1987-03-16 12:53:55 (floppy-user)ddb036-7s-g02:vtm
  0   4: I        1 page       1093 bytes 1987-04-15 09:55:04 (floppy-user)ddb057-7s-g02:vtm
  0   5: C        3 pages       977 bytes 1986-11-28 13:00:01 (floppy-user)ddb052-7s-g02:vtm
  0   6: C        2 pages      2100 bytes 1987-05-14 12:05:03 (floppy-user)ddb053-7s-g02:vtm
  0   7: I        1 page       1088 bytes 1987-02-09 12:43:40 (floppy-user)ddb079-7s-g02:vtm
  0   8: I        2 pages      2166 bytes 1987-05-13 09:13:39 (floppy-user)ddb080-7s-g02:vtm
  0   9: I        2 pages      2118 bytes 1987-05-14 12:04:03 (floppy-user)ddb083-7s-g02:vtm
  0  10: I        2 pages      3674 bytes 1987-04-15 10:04:25 (floppy-user)ddb090-7b-g02:vtm
  0  11: I        2 pages      2190 bytes 1987-05-07 12:32:33 (floppy-user)ddb092-7s-g02:vtm
  0  12: C        3 pages      1568 bytes 1987-03-13 10:36:15 (floppy-user)ddb099-7s-g02:vtm
  0  13: I        2 pages      2188 bytes 1987-05-11 10:24:02 (floppy-user)ddb090-7s-g02:vtm
  0  14: I        2 pages      2138 bytes 1987-04-15 10:52:03 (floppy-user)ddb093-7s-g02:vtm
  0  15: I        2 pages      2190 bytes 1987-05-07 12:28:48 (floppy-user)ddb091-7s-g02:vtm
  0  16: I        2 pages      3718 bytes 1987-05-07 14:29:29 (floppy-user)ddb093-7b-g02:vtm
  0  17: C        3 pages      3678 bytes 1987-04-15 10:57:00 (floppy-user)ddb100-7b-g02:vtm
  0  18: I        2 pages      2128 bytes 1987-04-15 10:57:59 (floppy-user)ddb100-8s-g02:vtm
  0  19: I        2 pages      3654 bytes 1987-04-15 10:59:17 (floppy-user)ddb100-8b-g02:vtm
  0  20: C        3 pages      2042 bytes 1987-04-15 10:56:00 (floppy-user)ddb100-7s-g02:vtm
  0  21: I        1 page       2014 bytes 1987-04-15 11:03:32 (floppy-user)ddb103-8s-g02:vtm
  0  22: C        3 pages      3724 bytes 1987-04-15 12:14:00 (floppy-user)ddb103-7b-g02:vtm
  0  23: C        3 pages      2138 bytes 1987-04-15 12:16:08 (floppy-user)ddb103-7s-g02:vtm
  0  24: I        2 pages      3530 bytes 1987-04-15 11:00:50 (floppy-user)ddb103-8b-g02:vtm
  0  25: I        1 page       1457 bytes 1987-02-03 13:17:26 (floppy-user)ddb105-7s-g02:vtm
  0  26: C        3 pages      1968 bytes 1987-05-06 11:49:32 (floppy-user)ddb113-7s-g02:vtm
  0  27: I        3 pages      3724 bytes 1987-05-06 11:45:25 (floppy-user)ddb113-7b-g02:vtm
  0  28: I        3 pages      3750 bytes 1987-05-06 11:51:27 (floppy-user)ddb110-7b-g02:vtm
  0  29: I        3 pages      2196 bytes 1987-05-06 11:53:08 (floppy-user)ddb110-7s-g02:vtm
  0  30: I      104 pages    292864 bytes 1987-05-07 09:28:33 (floppy-user)vtm-compound-g02:prog
  0  31: I        2 pages      3545 bytes 1987-05-04 15:01:56 (floppy-user)vtm-all-types:vtm
  0  32: I       17 pages    266240 bytes 1987-05-20 10:30:28 (floppy-user)inst-tables-g02:prog
  0  33: I        2 pages      3546 bytes 1987-04-23 12:15:22 (floppy-user)ddb999-g02:vtm
  0  34: I       34 pages     68696 bytes 1987-05-14 12:14:34 (floppy-user)ddbtables-g02:vtm
  0  35: I       42 pages     85884 bytes 1987-05-14 12:14:20 (floppy-user)vtm-arrays-g02:nrf
  0  36: I       34 pages     69530 bytes 1987-05-14 12:14:11 (floppy-user)vtm-2b-array-g02:brf
  0  37: I       34 pages     69528 bytes 1987-05-14 12:14:03 (floppy-user)vtm-1b-array-g02:brf
Directory size: 611 pages
Bit file size : 1 page
  • 210177K01-XX-01D COBOL-85 for ND-500/5000 release date 890227 8902 (gzipped image). Contents:
tingo@kg-t2$ ndfs -tl cobol-85.image
Directory name            : 210177k01-xx-01d
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I        8 pages     22528 bytes 1989-02-17 11:08:57 (floppy-user)description-file:desc
  0   1: I        9 pages     17089 bytes 1989-02-17 11:06:23 (floppy-user)cobol-85-k01:link
  0   2: I       64 pages    129253 bytes 1989-02-17 11:06:24 (floppy-user)cobol-85-k01:dseg
  0   3: I      130 pages    265213 bytes 1989-02-17 11:06:26 (floppy-user)cobol-85-k01:pseg
  0   4: I      142 pages    289308 bytes 1989-02-16 15:33:30 (floppy-user)cobol-85-lib-k01:nrf
  0   5: I        1 page        378 bytes 1989-02-07 15:36:20 (floppy-user)cobol-85-lib-k01:new
  0   6: I        1 page        880 bytes 1989-02-07 15:35:43 (floppy-user)cobol-85-lib-k01:old
  0   7: I        1 page        131 bytes 1987-07-12 23:49:56 (floppy-user)is-multi-k00:nrf
  0   8: I        1 page        258 bytes 1989-01-19 10:20:14 (floppy-user)is-multi-k00:new
  0   9: I        1 page        358 bytes 1989-01-19 10:22:21 (floppy-user)is-multi-k00:old
  0  10: I       58 pages    118784 bytes 1987-09-02 16:15:08 (floppy-user)isam-inter-k01:prog
  0  11: I       83 pages    211456 bytes 1989-02-13 14:41:12 (floppy-user)isam-service-k02:prog
Directory size: 611 pages
Bit file size : 1 page
  • 105226M07-NO-02D NOTIS-WP for ND-500 release date 870709 870507 (gzipped image). Contents:
tingo@kg-t2$ ndfs -tl notis-wp_nd500.image
Directory name            : 10526m07-no-2d
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I        8 pages     22528 bytes 1987-04-15 07:35:02 (floppy-user)description-file:desc
  0   1: I        0 pages         0 bytes 1987-04-15 07:27:59 (floppy-user)scratch-seg-01:link
  0   2: I        1 page       1029 bytes 1987-04-15 07:28:01 (floppy-user)scratch-seg-01:dseg
  0   3: I        1 page          5 bytes 1987-04-15 07:28:03 (floppy-user)scratch-seg-01:pseg
  0   4: I       37 pages     74337 bytes 1987-04-15 07:28:21 (floppy-user)notis-wp-no-m07:link
  0   5: I       84 pages    191563 bytes 1987-04-15 07:28:23 (floppy-user)notis-wp-no-m07:dseg
  0   6: I      279 pages    570263 bytes 1987-04-15 07:28:25 (floppy-user)notis-wp-no-m07:pseg
Directory size: 611 pages
Bit file size : 1 page
  • 210523E00-XX-01D Test Programs for ND-100 release date 870715 870108 (gzipped image). Contents:
tingo@kg-t2$ ndfs -tl test_nd100.image
Directory name            : 210523e00-xx-01d
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I       28 pages     56182 bytes 1986-10-30 13:42:50 (floppy-user)tpe-mon-100-a02:bpun
  0   1: I       11 pages     21504 bytes 1986-10-15 20:07:00 (floppy-user)cache-100-a00:test
  0   2: I       22 pages     43520 bytes 1986-10-16 10:25:35 (floppy-user)cache-110-a00:test
  0   3: I        9 pages     17920 bytes 1986-10-31 10:50:16 (floppy-user)colour-term-a00:test
  0   4: I       18 pages     36864 bytes 1986-12-11 17:27:36 (floppy-user)configuratio-d00:test
  0   5: I       35 pages     71680 bytes 1986-11-11 10:50:41 (floppy-user)disc-tema-i11:test
  0   6: I       23 pages     46592 bytes 1986-11-04 14:25:00 (floppy-user)floppy-strea-c00:test
  0   7: I       29 pages     58368 bytes 1986-10-16 10:37:37 (floppy-user)graphic-term-b00:test
  0   8: I        2 pages      3082 bytes 1986-04-17 14:47:07 (floppy-user)graphic-term-b00:font
  0   9: I       10 pages     19456 bytes 1986-10-31 12:02:28 (floppy-user)hdlc-megalin-d00:test
  0  10: I       17 pages     33280 bytes 1986-10-31 12:17:14 (floppy-user)instruction-c00:test
  0  11: I        5 pages     10240 bytes 1986-10-31 12:21:29 (floppy-user)lp-test-e00:test
  0  12: I        7 pages     13824 bytes 1986-10-31 12:24:28 (floppy-user)magtape-b00:test
  0  13: I       13 pages     25088 bytes 1986-10-31 12:30:42 (floppy-user)memory-d00:test
  0  14: I       17 pages     33792 bytes 1986-10-16 11:27:59 (floppy-user)paging-c00:test
  0  15: I       37 pages     75776 bytes 1986-12-04 12:10:42 (floppy-user)pioc-ether-a00:test
  0  16: I        4 pages      7680 bytes 1986-10-15 19:29:51 (floppy-user)power-fail-a00:test
  0  17: I       37 pages     75264 bytes 1986-10-16 10:14:44 (floppy-user)printers-a00:test
  0  18: I        6 pages     12288 bytes 1986-10-31 12:35:18 (floppy-user)sync-modem-b00:test
  0  19: I       13 pages     25600 bytes 1986-10-31 12:46:38 (floppy-user)terminal-asy-f00:test
  0  20: I       22 pages     44032 bytes 1986-10-31 12:54:14 (floppy-user)univers-dma-c00:test
Directory size: 611 pages
Bit file size : 1 page
  • dir: KOM, user: FL-US, Kermit (handwritten label) Kermit file transfer program (gzipped image). Contents:
tingo@kg-t2$ ndfs -tl kermit.image
Directory name            : kom
Object file index pointer : 508 SI: 0x1 (indexed)
User file index pointer   : 510 SI: 0x1 (indexed)
Bit file pointer          : 306 SI: 0x0 (contiguous)
No. of unreserved pages   : 1
Files:
  0   0: I       23 pages     45568 bytes 1989-06-23 15:32:19 (floppy-user)kermit:prog
  0   1: I        1 page        420 bytes 1989-06-23 15:32:34 (floppy-user)kermit:hlib
  0   2: I        4 pages      6915 bytes 1989-06-23 15:32:38 (floppy-user)kermit:help
Directory size: 611 pages

8 inch

The 8-inch floppies I have.

2016-06-30: from a colleague at work I got a 8 inch floppy.

  • 210518C01-NO-01S USER-ENVIRONMENT. User name: FLOPPY-USER, Prod. release date: 861124 861021. No idea if it still works or not. 2018-07-25: The 8-inch floppy is still readable, check out the ND-210518C page.

tape

2016-05-28: in today's haul I got 9 (magnetic) tapes, the spools are about 7 inches in diameter (add about one centimeter for the protective case), the tape itself is about 0.5 inch wide. some tapes are unlabeled, most carry a "Racal-Zonal" label, one has "Fully Tested to 3200 F C I", "Racal-Zonal", "CALCULUS COMPUTER TAPE" on the same label. (Note to self: more tapes are available, if I can figure out a way to read them)

  • 9 x 0.5 inch wide tapes, perhaps this is 9-track tape? Is this what is called CCT (computer compatible tape)?

Luckily, the tapes have an index / contents written down on paper stored inside the tape box.

paper tape

2016-07-28: Another haul, and I got two trays of paper tapes, see picture
Paper tapes.png

2016-05-28: in this haul I got a paper tape, see below. (Note to self: more paper tapes are available, if interested.)

  • 1 x 8-hole paper tape containing RUNOFF:SYMB (text both punched and written with pencil on tape)

References

  1. Bitsavers - Facit
  2. Digitronics 2540 Perforated Tape Reader - December 1971 (PDF)
